TCP/IP & RS485 Door Access Controller, 1 or 2 Doors
Networked controller board for one or two doors with TCP/IP and RS485 host links, Wiegand entry/exit readers, 5 A lock relays and storage for 30,000 cards.
Send us your controller model, card type and install environment. We'll shortlist compatible hardware and quote within 24 hours.
Networked controller boards for centralized one-door or two-door installations. Wiegand inputs, lock relays and local records form the hardware base; software and enclosure choices complete the project.
Networked controller board for one or two doors with TCP/IP and RS485 host links, Wiegand entry/exit readers, 5 A lock relays and storage for 30,000 cards.
NC-110 is offered for one or two doors, with entry and exit Wiegand inputs for each door. It keeps up to 30,000 cards and 100,000 event records locally and communicates with the host over Ethernet or RS485. These are host links; the RS485 listing does not establish OSDP reader-input support. Select the door-count variant before laying out readers and lock circuits.
The board supports functions such as anti-passback and interlock, but their configuration depends on the management software and installation. Confirm the supported platform, reader model, Wiegand format and expected behavior when the host connection is unavailable. The relay contact rating does not establish the complete lock wiring or power budget.
The published dimensions describe the board, while the product photo shows a cabinet. Confirm whether the quotation covers the board or an enclosed assembly, including any power supply, mounting parts and wiring space. Use the power-supply category to compare options; a category link does not establish that an enclosure or supply is included.
Maglock wiring with dry-relay COM/NC: keypad and reader diagrams, REX signals, approved egress release paths and manufacturer-specific suppression.
Wiegand 26-bit is an even parity bit, 8-bit facility code, 16-bit card number and odd parity bit. Convert card numbers to hex and back with the calculator.
Wire a Wiegand reader red to +12V, black to GND, green to D0 and white to D1, with a shared ground. Diagrams, cable gauge, 150 m limit and fixes inside.
Plan an RFID vehicle access control system: UHF windshield tags, long-range lane readers, Wiegand controllers and barrier triggering. Lane BOM and samples.
Apartment building access control hardware: anti-clone readers with matched fob sets, QR visitor codes, 4G controllers for rentals and UHF tags for gates.
Turnstile card readers, QR scanners and face terminals for tripod, swing and speed gates, with Wiegand, RS485, RS232 or TTL output to the gate board.
The one-door version has two Wiegand reader inputs and the two-door version has four, allowing entry and exit reading per door.
Both host interfaces are listed for NC-110. The host software must support the board’s communication protocol and configuration. Reader inputs are listed as Wiegand; the RS485 host label does not establish OSDP reader-input support.
The published dimensions describe the board, but the photo shows a cabinet. Confirm the quoted supply scope, power supply, included mounting parts and enclosure drawing before ordering; cabinet inclusion or board-only supply is not established by the available specifications.
