NC-110 TCP/IP & RS485 Door Access Controller, 1 or 2 Doors

Networked controller board for one or two doors with TCP/IP and RS485 host links, Wiegand entry/exit readers, 5 A lock relays and storage for 30,000 cards.

  • 1-door (2 readers) or 2-door (4 readers) builds on the same 160 × 106 mm board
  • TCP/IP Ethernet and RS485 host links for LAN or serial-bus sites
  • Local storage for 30,000 cards and 100,000 event logs
  • Lock relay rated 36 V DC / 5 A; auxiliary relay 36 V DC / 2 A
  • Anti-passback, interlock, multi-card opening and remote door control
Doors
1 (NC-110-1D) or 2 (NC-110-2D)
Host interface
TCP/IP (Ethernet) + RS485
Reader inputs
Wiegand, 2 or 4
Capacity
30,000 cards / 100,000 logs
Power
12 V DC ±20%, ≤ 0.5 A
Lock relay
36 V DC, 5 A max
Reply within 24 hours Tested before dispatch Worldwide shipping

TCP/IP & RS485 Door Access Controller, 1 or 2 Doors: overview

NC-110 is a networked access controller for one or two doors managed from a host system. Each door has entry and exit Wiegand reader inputs and a lock relay. TCP/IP Ethernet and RS485 are listed as host communication links. The reader inputs are specified as Wiegand; an RS485 host connection does not establish OSDP reader support.

The board runs embedded Linux on a 32-bit 400 MHz processor with 32 Mbit RAM and 256 Mbit flash, and stores up to 30,000 cards and 100,000 events locally. A hardware watchdog is provided. The 12 V input has over-current, over-voltage and reverse-polarity protection; reader power has over-current protection, and transient over-voltage protection is listed on the I/O and communication ports.

Listed access functions include anti-passback, interlock, multi-card opening and remote open or close. Linkage triggers include door state, card events, I/O points and card number. Confirm how the supplied management software and firmware configure these functions, including the required operation when the host is disconnected.

Integration and supply checks

The board supply is 12 V DC ±20% with current no more than 0.5 A. The listed lock relay maximums are 36 V DC and 5 A; auxiliary relay maximums are 36 V DC and 2 A. These are contact ratings, not a complete lock-wiring approval or power budget. Confirm the lock load, power supply, wiring and required suppression for the selected installation before connecting a lock.

The published 160 × 106 × 1.6 mm dimensions describe the board. The product photo shows a cabinet, but cabinet and power-supply inclusion are not established by the available specifications. State whether the quote should cover the board or an enclosed assembly and confirm the included parts and mounting drawing before ordering.

For an integration quote, send NC-110-1D or NC-110-2D, the reader model and Wiegand format, management software and firmware, lock details, quantity and delivery country. Verify the proposed reader and host combination with a sample before a multi-door rollout.

More features

  • Multiple Wiegand card formats and PIN keypad readers; confirm the exact output format
  • Hardware watchdog plus surge, over-voltage and reverse-polarity protection

NC-110 specifications

Processing & memory

Processor32-bit, 400 MHz
RAM / flash32 Mbit / 256 Mbit
Operating systemEmbedded Linux
Card capacity30,000
Event log capacity100,000
WatchdogBuilt-in hardware watchdog

Interfaces

Host communicationTCP/IP (Ethernet) and RS485
Reader inputsWiegand: 2 (NC-110-1D) / 4 (NC-110-2D)
Reader compatibilityMultiple Wiegand card formats; PIN keypad readers
Lock outputs1 / 2
Auxiliary inputsNone / 2
Auxiliary outputs1 / 2
Exit buttonRequest-to-exit input supported

Access logic

Anti-passbackYes
InterlockYes
Multi-card openingYes, by user group
Remote open / closeYes, from management software
Linkage triggersDoor state, card events, I/O points, card number

Electrical

Supply voltage12 V DC ±20%
Board current≤ 0.5 A
Lock relay rating36 V DC max, 5 A max
Auxiliary relay rating36 V DC max, 2 A max
Input protectionOver-current, over-voltage and reverse-polarity
Reader power outputOver-current protected
Port protectionTransient over-voltage protection on all I/O and communication ports

Mechanical & environment

Board size160 × 106 × 1.6 mm
Operating temperature0 to +55 °C
Operating humidity10–80% RH

1-door vs 2-door configuration

ItemNC-110-1DNC-110-2D
Doors controlled12
Lock relay outputs12
Wiegand reader inputs2 (entry + exit)4 (entry + exit per door)
Request-to-exit buttonSupportedSupported
Auxiliary inputsNone2
Auxiliary outputs12
Host communicationTCP/IP + RS485TCP/IP + RS485
Board size160 × 106 × 1.6 mm160 × 106 × 1.6 mm

Specifications can change between production batches. Confirm the current revision with us before placing volume orders.

Ordering options

Request a quote for a configuration below, or add one or more to your inquiry list. Specify NC-110-1D or NC-110-2D, quantity, delivery country, reader model and Wiegand format, host software, lock load and required cabinet/power-supply scope.

SKUConfigurationActions
NC-110-1D Single-door controller board: 1 lock relay, 2 Wiegand reader inputs (entry/exit), 1 auxiliary output, TCP/IP + RS485
NC-110-2D Two-door controller board: 2 lock relays, 4 Wiegand reader inputs, 2 auxiliary inputs, 2 auxiliary outputs, TCP/IP + RS485

Where the NC-110 is used

  • Office entrance with a card reader outside and an exit reader inside, logged to a central server
  • Two controlled doors using configured interlock rules, with the required operation checked in the management software
  • Gym or club entry with entry/exit reader events used for configured anti-passback decisions
  • Retrofit sites with an existing RS485 backbone and no Ethernet at each door
Parking

RFID Vehicle Access Control & Parking

Plan an RFID vehicle access control system: UHF windshield tags, long-range lane readers, Wiegand controllers and barrier triggering. Lane BOM and samples.

NC-110 FAQ

What is the difference between NC-110-1D and NC-110-2D?

Both use the same 160 × 106 mm board with TCP/IP and RS485. The 1-door build has one lock relay, two Wiegand reader inputs and one auxiliary output; the 2-door build has two relays, four reader inputs, two auxiliary inputs and two auxiliary outputs.

Which card readers can I connect?

The listed reader interface is Wiegand, with multiple card formats and PIN keypad support. Confirm the exact reader model, card-number bit layout and electrical requirements with the proposed controller firmware. A reader having Wiegand output alone does not prove that every format or keypad behavior is supported.

Can the lock relay switch a magnetic lock directly?

The listed maximum lock-relay contact ratings are 36 V DC and 5 A. Those ratings alone do not approve a particular magnetic lock or wiring arrangement. Confirm the lock load, supply, contact wiring and suppression requirements for the selected installation. Include reader and controller loads in the power budget.

Are TCP/IP and RS485 host links also OSDP reader inputs?

TCP/IP Ethernet and RS485 are listed for communication with the host management system; reader connections are listed separately as Wiegand. No OSDP reader-input support is established for NC-110. Confirm the host protocol, software and firmware for the selected link; do not select this board as an OSDP reader controller based on its RS485 label.

Which access control software does it work with?

That depends on your platform. Tell us which management software or SDK the project uses and we will confirm compatibility and firmware requirements before you order.

Does the quoted controller include the cabinet and power supply?

The listed dimensions, 160 × 106 × 1.6 mm, describe the board. The photo shows an enclosed unit, but it does not establish what is included in an order. Ask for the board or enclosed-assembly scope, power-supply details, included parts and mounting drawing to be confirmed on the quotation.
