PC-120 Desktop RFID Card Reader/Writer, USB, 107 mm Square
Square 107 mm USB desktop reader: 125 kHz EM or 13.56 MHz UID read-only versions, plus encoders for MIFARE Classic sectors, CPU cards, DESFire EV1 files and NTAG.
- 107 × 107 × 24 mm square desktop housing for reception and enrollment counters
- Four versions: 125 kHz EM read-only, 13.56 MHz UID read-only, sector encoder, CPU/NTAG encoder
- Reads UIDs of MIFARE Classic, DESFire EV1/EV2/EV3, MIFARE Plus, Ultralight, NTAG2xx and CPU cards
- MIFARE Classic 1K/4K sector read/write and key change on PC-120-MS and PC-120-MS-N
- PC-120-MS-N adds DESFire EV1 file, CPU-card and Ultralight/NTAG2xx read/write
- Frequency
- 125 kHz or 13.56 MHz (by version)
- Standards
- ISO/IEC 14443A/B
- Interface
- USB, driver-free
- Read range
- ≥ 30 mm (card-dependent)
- Power
- 5 V DC via USB, ≤ 150 mA
- Dimensions
- 107 × 107 × 24 mm
Reply within 24 hours Tested before dispatch Worldwide shipping
Desktop RFID Card Reader/Writer, USB, 107 mm Square: overview
The PC-120 is a square USB desktop reader for card enrollment and encoding at front desks, security offices and membership counters. Its 107 × 107 × 24 mm footprint gives staff a generous target for presenting a card, and it runs driver-free from the host's 5 V USB port on Windows, Android and Linux.
Four versions cover the usual desk jobs. PC-120-E reads 125 kHz EM4100, EM4102 and EM4200-compatible cards and fobs, while PC-120-M reads 13.56 MHz UIDs from MIFARE Classic, DESFire, MIFARE Plus, Ultralight, NTAG2xx and CPU cards. PC-120-MS adds MIFARE Classic 1K/4K sector read/write and key changes through host software. PC-120-MS-N further supports CPU-card writing, DESFire EV1 application files and Ultralight/NTAG read/write.
Read-only versions send the card number in a format you configure in software, so it matches the numbering held in your access or attendance platform. PC-120-MS-N switches between active output and passive, command-driven operation, and its active output format can be configured too. Firmware updates are applied online.
Integration notes
Expect a read distance of 30 mm or more depending on the card and surroundings, with each read finishing in under 100 ms. Operating current is 150 mA or less. The reader is rated for −10 to +60 °C at 15–90% relative humidity. If you need a smaller rectangular unit with a metal frame or ICODE, iCLASS and FeliCa support, look at the PC-110 instead.
More features
- Driver-free USB, 5 V bus power, ≤ 150 mA; Windows, Android and Linux
- Configurable card-number output format; online firmware update
PC-120 specifications
RF & credentials
| Frequency | 125 kHz (PC-120-E); 13.56 MHz (all other versions) |
|---|---|
| Standards | ISO/IEC 14443A, ISO/IEC 14443B |
| 125 kHz credentials | EM4100, EM4102 and EM4200-compatible thick cards, thin cards and key fobs |
| 13.56 MHz UID reading | MIFARE Classic Mini/EV1, MIFARE DESFire EV1/Light/EV2/EV3, MIFARE Plus S/X, MIFARE Ultralight/Ultralight C/Ultralight EV1, NTAG2xx and CPU (microprocessor) cards |
| Read/write functions | By version; see the version comparison table |
| Read distance | ≥ 30 mm (depends on card type and environment) |
| Read time | < 100 ms within read distance |
| Read speed | 0.2 s |
| Interval between reads | 0.5 s |
Interfaces & software
| Host interface | USB, driver-free |
|---|---|
| Operating systems | Windows, Android, Linux |
| Output format | Card-number format configurable in software |
| Reading modes | Active or passive, switchable (PC-120-MS-N) |
| Firmware | Online update supported |
Electrical
| Supply | 5 V DC via USB |
|---|---|
| Current | ≤ 150 mA |
Mechanical & environment
| Dimensions | 107 × 107 × 24 mm |
|---|---|
| Housing | Square desktop housing |
| Operating temperature | −10 to +60 °C (14 to 140 °F) |
| Storage temperature | −20 to +70 °C (−4 to +158 °F) |
| Operating humidity | 15–90% RH |
Version comparison
| Function | PC-120-E | PC-120-M | PC-120-MS | PC-120-MS-N |
|---|---|---|---|---|
| Frequency | 125 kHz | 13.56 MHz | 13.56 MHz | 13.56 MHz |
| EM4100/EM4102/EM4200 card read | Yes | — | — | — |
| 13.56 MHz UID read (MIFARE, DESFire, Plus, Ultralight, NTAG2xx, CPU) | — | Yes | Yes | Yes |
| MIFARE Classic 1K/4K sector read/write, key change | — | — | Yes | Yes |
| CPU card: encrypted content read, card write | — | — | — | Yes |
| DESFire EV1 application file read/write | — | — | — | Yes |
| Ultralight / Ultralight C / NTAG2xx read/write | — | — | — | Yes |
| Operation | Outputs card number | Outputs card number | Driven by host software | Active output or host commands |
| Configurable output format | Yes | Yes | — | Yes (active mode) |
Specifications can change between production batches. Confirm the current revision with us before placing volume orders.
Ordering options
Quote the SKU that matches your frequency, interface and mounting. Not sure? Send us your controller model and we will pick the variant for you.
| SKU | Configuration | Actions |
|---|---|---|
| PC-120-E | 125 kHz EM read-only square desktop reader (EM4100/EM4102/EM4200-compatible), configurable output | |
| PC-120-M | 13.56 MHz UID read-only square desktop reader for MIFARE, DESFire, Plus, Ultralight, NTAG2xx and CPU cards | |
| PC-120-MS | 13.56 MHz reader/writer: UID reading plus MIFARE Classic 1K/4K sector read/write and key change | |
| PC-120-MS-N | 13.56 MHz reader/writer: adds CPU-card writing, DESFire EV1 files, Ultralight/NTAG read/write, active/passive modes |
Where the PC-120 is used
- Registering new employee badges at an HR or security desk
- Writing sector keys and data to MIFARE Classic cards for an apartment or elevator system
- Issuing NTAG2xx membership cards at a gym front desk
- Checking a returned card's UID before re-issuing it to a new user
Elevator Access Control Readers
Elevator card readers for car panels and lift lobbies: anti-clone encrypted cards, QR codes for visitors, Wiegand or RS485 output to the floor controller.
Gym & 24/7 Fitness Club Access Control Hardware
Gym access control system hardware for 24/7 clubs: fob and wristband readers, face and QR terminals, anti-passback controllers and no-touch exit buttons.
PC-120 FAQ
How does the PC-120 differ from the PC-110?
Up to the MS-N tier the card functions are the same. The PC-120 uses a 107 × 107 × 24 mm square housing, while the PC-110 measures 110 × 80 × 16.2 mm, has a metal middle frame and offers an extra ICODE/iCLASS/FeliCa tier.
Can the read-only versions write cards?
No. PC-120-E and PC-120-M only read card numbers. Choose PC-120-MS for MIFARE Classic sector writing, or PC-120-MS-N for CPU-card, DESFire EV1 file and NTAG writing.
Is a driver needed?
No. The reader is driver-free over USB, takes its 5 V supply from the port and works with Windows, Android and Linux hosts.
Does it read ICODE (ISO/IEC 15693) tags?
No PC-120 version lists ISO/IEC 15693 card support. Use the PC-110-MS-N-IC, PC-140 or PC-150 for ICODE tags.
How fast is a read?
A card inside the read distance is read in under 100 ms. Rated read speed is 0.2 s, with 0.5 s between consecutive reads.
