LT-120 EAS + UHF RFID Hard Tag with Hook Lock, 72 × 30 mm
Dual-technology ABS hard tag, 72 × 30 × 20 mm, with a hook lock: UHF RFID (860–960 MHz, 2–5 m) for inventory plus AM 58 kHz or RF 8.2 MHz EAS.
- UHF RFID and EAS in one reusable hard tag for apparel, bags, shoes and accessories
- Hook-lock cylinder for stores that use hook-type detachers
- UHF antenna rated 860–960 MHz, covering 902–928 MHz and 865–868 MHz readers
- Listed read distance 2–5 m (up to 16 ft) with a UHF reader
- AM 58 kHz or RF 8.2 MHz EAS element to match existing gates
- RFID frequency
- 860–960 MHz (UHF)
- EAS
- AM 58 kHz or RF 8.2 MHz
- Read range
- 2–5 m (up to 16 ft)
- Chip
- Impinj Monza R6
- Lock
- Hook lock
- Dimensions
- 72 × 30 × 20 mm
Reply within 24 hours Tested before dispatch Worldwide shipping
EAS + UHF RFID Hard Tag with Hook Lock, 72 × 30 mm: overview
The LT-120 lets a retailer run RFID inventory and electronic article surveillance from the same reusable tag. A UHF chip gives each item a readable EPC for stock counts, and an EAS element triggers the store's existing exit gates if the tag leaves unreleased. The ABS body is 72 × 30 × 20 mm and uses a hook-lock cylinder.
On the RFID side, an Impinj Monza R6 chip sits on an antenna rated for 860–960 MHz. That covers readers on the FCC 902–928 MHz band and the ETSI 865–868 MHz band, so one tag specification can serve stores in both regions. Listed read distance is 2–5 m (up to 16 ft) with a UHF reader, which is enough to count a rail of garments or a shelf of shoes from the aisle.
For EAS, choose the element that matches your pedestals: AM 58 kHz (LT-120-AM) or RF 8.2 MHz (LT-120-RF). Each tag carries one of the two.
Integration notes
A hook lock is opened with a hook-type detacher rather than a magnetic one, so check the tools at your tills before switching from magnetic-lock tags such as the LT-110. Encode EPCs with an EPC Gen2 reader-writer before tagging, and trial the tag on samples to confirm gate detection and detacher release.
More features
- Impinj Monza R6 chip in a 72 × 30 × 20 mm ABS housing
LT-120 specifications
RFID
| Frequency | 860–960 MHz |
|---|---|
| Reader bands covered | FCC 902–928 MHz and ETSI 865–868 MHz |
| Air protocol | EPC Gen2 / ISO/IEC 18000-6C |
| Chip | Impinj Monza R6 |
| Read range | 2–5 m (up to 16 ft) with a UHF reader |
EAS
| Technology | AM 58 kHz (LT-120-AM) or RF 8.2 MHz (LT-120-RF) |
|---|---|
| Release | Hook-type detacher |
Mechanical
| Housing material | ABS |
|---|---|
| Dimensions | 72 × 30 × 20 mm |
| Lock cylinder | Hook lock |
Use
| Intended applications | Retail item-level inventory, asset tagging, anti-theft |
|---|
EAS versions
| Variant SKU | EAS technology | RFID band | Lock | Size |
|---|---|---|---|---|
| LT-120-AM | AM 58 kHz | 860–960 MHz | Hook | 72 × 30 × 20 mm |
| LT-120-RF | RF 8.2 MHz | 860–960 MHz | Hook | 72 × 30 × 20 mm |
One EAS element per tag. The LT-110 offers the same options with a magnetic lock.
Specifications can change between production batches. Confirm the current revision with us before placing volume orders.
Ordering options
Quote the SKU that matches your frequency, interface and mounting. Not sure? Send us your controller model and we will pick the variant for you.
| SKU | Configuration | Actions |
|---|---|---|
| LT-120-AM | EAS + UHF hard tag, AM 58 kHz EAS, UHF 860–960 MHz, hook lock, 72 × 30 × 20 mm ABS | |
| LT-120-RF | EAS + UHF hard tag, RF 8.2 MHz EAS, UHF 860–960 MHz, hook lock, 72 × 30 × 20 mm ABS |
Where the LT-120 is used
- Store group standardizing on hook detachers that wants RFID stock counts on the same tag
- Outlet stores on 8.2 MHz RF gates moving to UHF cycle counting
- Sports and footwear retailers counting shoe walls from the aisle with a handheld
- Rental or loan items that need theft deterrence and an EPC for check-in and check-out
RFID Asset & Tool Tracking
Build an RFID asset tracking system: on-metal, ceramic and tie-on tags matched to each asset, handheld audits, smart cabinets and IP67 HF heads for tooling.
LT-120 FAQ
What detacher opens the LT-120?
It has a hook-lock cylinder, so it is released with a hook-type detacher, not a magnetic one. Try samples with your current tools before ordering.
Can I order it for AM and for RF gates?
Yes, as two versions: LT-120-AM carries an AM 58 kHz element and LT-120-RF an RF 8.2 MHz element. A single tag does not carry both.
Will it read in both the US and Europe?
Yes. The UHF antenna is rated for 860–960 MHz, which includes the FCC 902–928 MHz and ETSI 865–868 MHz reader bands.
How far away can a reader pick it up?
The listed range is 2–5 m (up to 16 ft) with a UHF reader. Expect less on metal displays or in dense stacks.
