CR-230 Metal Wiegand Card Reader, 125 kHz / 13.56 MHz / LEGIC
Keyless 93 mm metal reader with Wiegand 26/34/66 output. Five versions cover 125 kHz EM, MIFARE-family UIDs, protected sector data, FeliCa numbers and LEGIC cards.
- Five versions: 125 kHz EM, 13.56 MHz UID, MIFARE sector/CPU data, FeliCa number or LEGIC
- Reads MIFARE Classic, Plus, DESFire EV1/EV2/EV3, Ultralight and NTAG2xx UIDs
- LEGIC version reads LEGIC card numbers and protected content, output as Wiegand 34
- Wiegand 26/34 on all versions; Wiegand 66 on CR-230-MS and CR-230-MS-FC
- Configuration card sets Wiegand length, read mode, card key and number format
- Frequency
- 125 kHz (-E) or 13.56 MHz (all other versions)
- Output
- Wiegand 26/34; 66 on -MS versions; 34 on -LG
- Credentials
- EM4100/EM4200, MIFARE, DESFire, NTAG, ICODE, iCLASS CSN, FeliCa, LEGIC
- Power
- 12 V DC ±5%, ≤ 200 mA
- Dimensions
- 93 × 93 × 19 mm, metal, no keypad
- Operating temperature
- –10 to +60 °C
Reply within 24 hours Tested before dispatch Worldwide shipping
Metal Wiegand Card Reader, 125 kHz / 13.56 MHz / LEGIC: overview
The CR-230 is a card-only 93 × 93 mm metal reader for integrators who want one housing across several credential technologies. It passes card data to any controller, turnstile board or lift panel with a Wiegand input and runs from 12 V DC at no more than 200 mA. Five read options cover 125 kHz EM cards, 13.56 MHz UIDs, protected MIFARE and CPU-card data, FeliCa numbers and LEGIC credentials.
The 13.56 MHz versions return the serial number of MIFARE Classic, MIFARE Plus, DESFire EV1/EV2/EV3, Ultralight and NTAG cards. CR-230-MS adds keyed reading of MIFARE Classic 1K/4K sectors and CPU-card data, plus ISO/IEC 15693 (ICODE) UIDs and the iCLASS card serial number (CSN) only. CR-230-MS-FC keeps the CPU-card data read, drops MIFARE Classic sector reading and adds FeliCa card numbers. CR-230-LG reads LEGIC card numbers and protected LEGIC content; confirm module details and your LEGIC project setup with us before you specify it.
Wiegand length, read mode, card key and number format are changed by presenting a configuration card, so one stocked part can be adapted per door. Response is under 120 ms once a card enters the field, the circuit has ESD and miswiring protection, and the reader is designed to cope with metal shielding on steel frames.
Integration notes
The pigtail uses red for +12 V, black for GND, green for D0 and white for D1; purple and gray take buzzer and LED control from the panel. Tie the yellow lead to GND to lock the output at Wiegand 26. Otherwise select 26 or 34 bits by configuration card, or 66 bits on the MS versions. No ingress rating is published, so mount it indoors or under cover.
More features
- Keyless 93 × 93 × 19 mm metal housing; 12 V DC, ≤ 200 mA; response < 120 ms
CR-230 specifications
RF & credentials
| Frequency | 125 kHz (CR-230-E); 13.56 MHz (CR-230-M, -MS, -MS-FC, -LG) |
|---|---|
| Protocols | ISO/IEC 14443A, ISO/IEC 14443B, ISO/IEC 15693 |
| 125 kHz credentials | EM4100, EM4102, EM4200-compatible thick cards, thin cards and key fobs |
| 13.56 MHz UID read | MIFARE Classic Mini/EV1, MIFARE Plus S/X, MIFARE DESFire EV1/EV2/EV3/Light, MIFARE Ultralight/Ultralight C/Ultralight EV1, NTAG2xx; ISO/IEC 14443 CPU cards (-M, -MS, -MS-FC) |
| Protected data read | MIFARE Classic 1K/4K sectors and CPU-card data (-MS); CPU-card data (-MS-FC); LEGIC card content (-LG) |
| Other card numbers | ISO/IEC 15693 UID (e.g. ICODE 2) and iCLASS CSN only (-MS, -MS-FC); FeliCa card number (-MS-FC); LEGIC card number (-LG) |
| Response time | < 120 ms within the read field |
Interfaces
| Output | Wiegand 26/34 (-E, -M); Wiegand 26/34/66 (-MS, -MS-FC); Wiegand 34 (-LG) |
|---|---|
| Setup | Configuration card: Wiegand format, read mode, card key, card-number format |
| Controller inputs | Buzzer control, LED control |
| Format lead (yellow) | Connect to GND to fix the output at Wiegand 26 |
Electrical
| Supply voltage | 12 V DC (±5%) |
|---|---|
| Operating current | ≤ 200 mA |
| Protection | ESD protection, miswiring protection |
Mechanical & environment
| Housing | Metal, card-only (no keypad); designed to resist metal shielding |
|---|---|
| Dimensions | 93 × 93 × 19 mm (±0.2 mm) |
| Operating temperature | –10 to +60 °C |
| Storage temperature | –20 to +80 °C |
| Operating humidity | 15–90% RH |
| Ingress rating | Not specified (indoor or sheltered mounting) |
Variant comparison
| Variant | Frequency | Card numbers read | Protected data read | Wiegand output |
|---|---|---|---|---|
| CR-230-E | 125 kHz | EM4100/EM4102/EM4200-compatible cards and fobs | — | 26 / 34 |
| CR-230-M | 13.56 MHz | MIFARE Classic, Plus, DESFire, Ultralight, NTAG2xx, CPU cards | — | 26 / 34 |
| CR-230-MS | 13.56 MHz | As -M, plus ISO/IEC 15693 (ICODE) UID and iCLASS CSN | MIFARE Classic 1K/4K sectors, CPU-card data | 26 / 34 / 66 |
| CR-230-MS-FC | 13.56 MHz | As -M, plus ICODE UID, iCLASS CSN and FeliCa card number | CPU-card data | 26 / 34 / 66 |
| CR-230-LG | 13.56 MHz | MIFARE Classic, Plus, DESFire, Ultralight, NTAG2xx; LEGIC card number | LEGIC card content | 34 |
Choose by the credentials already issued on site. "CPU" = ISO/IEC 14443 CPU (smart) cards; iCLASS support is card serial number (CSN) only.
Wire colors
| Wire | Function |
|---|---|
| Red | +12 V DC |
| Black | GND |
| Green | Wiegand D0 |
| White | Wiegand D1 |
| Purple | Buzzer control input |
| Gray | LED control input |
| Yellow | Connect to GND to fix the output at Wiegand 26 |
Specifications can change between production batches. Confirm the current revision with us before placing volume orders.
Ordering options
Quote the SKU that matches your frequency, interface and mounting. Not sure? Send us your controller model and we will pick the variant for you.
| SKU | Configuration | Actions |
|---|---|---|
| CR-230-E | 125 kHz version: EM4100/EM4102/EM4200-compatible thick cards, thin cards and key fobs; Wiegand 26/34. | |
| CR-230-M | 13.56 MHz UID version: MIFARE Classic, Plus, DESFire EV1/EV2/EV3/Light, Ultralight, NTAG2xx and CPU card UIDs; Wiegand 26/34. | |
| CR-230-MS | 13.56 MHz secure-read version: -M UIDs plus MIFARE Classic 1K/4K sector and CPU-card data, ICODE UID, iCLASS CSN only; Wiegand 26/34/66. | |
| CR-230-MS-FC | 13.56 MHz version: -M UIDs plus CPU-card data, ICODE UID, iCLASS CSN only and FeliCa card number; Wiegand 26/34/66. | |
| CR-230-LG | 13.56 MHz LEGIC version: MIFARE-family and NTAG UIDs plus LEGIC card number and protected content; Wiegand 34. |
Where the CR-230 is used
- European offices and campuses adding LEGIC-card doors to a Wiegand panel
- Mixed EM and MIFARE sites that want one reader housing with per-door versions
- Lift lobbies and turnstile lanes that accept Wiegand 26 or 34 input
- Sites whose staff already carry FeliCa-based cards, using CR-230-MS-FC
Elevator Access Control Readers
Elevator card readers for car panels and lift lobbies: anti-clone encrypted cards, QR codes for visitors, Wiegand or RS485 output to the floor controller.
Turnstile & Speed-Gate Readers: QR, RFID and Face
Turnstile card readers, QR scanners and face terminals for tripod, swing and speed gates, with Wiegand, RS485, RS232 or TTL output to the gate board.
CR-230 FAQ
Which CR-230 version reads LEGIC cards?
CR-230-LG reads LEGIC card numbers and protected LEGIC content, plus MIFARE-family and NTAG UIDs, and outputs Wiegand 34. Send us your LEGIC card type and project setup so we can confirm compatibility before you order.
Can it read HID iCLASS cards?
CR-230-MS and CR-230-MS-FC read the iCLASS card serial number (CSN) only. They do not decode the secure credential, so enroll iCLASS cards by CSN in your access software.
How do I switch between Wiegand 26 and 34?
Connect the yellow lead to GND to fix the output at Wiegand 26. Without that link, choose the format with a configuration card; the MS versions also offer Wiegand 66.
Can the CR-230 go on a steel door frame?
Yes. The reader is designed to resist metal shielding, which suits steel frames and metal-clad entrances. Test with your own cards at the final mounting position before a full rollout.
Is there a keypad version?
Yes. The CR-220 uses the same 93 × 93 mm metal format and adds a touch keypad for card-plus-PIN doors.
