TP-150 Tamper-Proof 13.56 MHz Card Reader, Metal Frame, IP65
13.56 MHz tamper-alarm reader with a metal middle frame for metal mounting surfaces: IP65, 93 mm square, encrypted CPU card reading, Wiegand or RS485.
- Metal middle frame limits the effect of metal mounting surfaces on reading
- 13.56 MHz: MIFARE Classic, DESFire EV1/EV2, Ultralight/C, NTAG2xx, NFC Forum Type 1/2/4
- Reads encrypted CPU smart-card content for anti-copy credentials
- IP65, tamper alarm, 93.3 × 93 × 19.3 mm square housing
- Wiegand or RS485 output; firmware updates over RS485
- Frequency
- 13.56 MHz
- Mounting
- Metal middle frame for metal surfaces
- Output
- Wiegand, RS485
- Read range
- 0–3 cm
- IP rating
- IP65
- Dimensions
- 93.3 × 93 × 19.3 mm
Reply within 24 hours Tested before dispatch Worldwide shipping
Tamper-Proof 13.56 MHz Card Reader, Metal Frame, IP65: overview
TP-150 is a 13.56 MHz tamper-alarm reader built with a metal middle frame, which reduces the effect a metal mounting surface has on reading. That makes it the model to specify for steel door frames, metal gate posts and turnstile cabinets.
It reads MIFARE Classic, MIFARE DESFire EV1/EV2, MIFARE Ultralight and Ultralight C, NTAG2xx, NFC Forum Type 1/2/4 tags and CPU smart cards under ISO/IEC 14443A/B and ISO/IEC 18092. The encrypted content of CPU cards can be read, giving a credential that resists simple copying. Read range is 0–3 cm.
The 93.3 × 93 × 19.3 mm housing is rated IP65 and raises a tamper alarm if the reader is taken off its mount. Operating temperature is –20 to +65 °C, with storage down to –40 °C.
Integration notes
Output is Wiegand or RS485 from a 9–15 V DC supply; at 12 V allow about 100 mA on standby and 150 mA while reading. Firmware and settings are updated over RS485 with the management utility. A touch-keypad version is available in the same housing. No third-party certification is listed for this model.
More features
- Card-only or touch-keypad version
TP-150 specifications
RF & credentials
| Frequency | 13.56 MHz |
|---|---|
| HF standards | ISO/IEC 14443A, ISO/IEC 14443B, ISO/IEC 18092 |
| HF cards and tags | MIFARE Classic, MIFARE DESFire EV1/EV2, MIFARE Ultralight, MIFARE Ultralight C, NTAG2xx, CPU (microprocessor) smart cards, NFC Forum Type 1/2/4 tags |
| Encrypted read | Reads encrypted content of CPU smart cards (anti-copy) |
| Read range | 0–3 cm (depends on installation and card) |
Interfaces & management
| Communication | Wiegand, RS485 |
|---|---|
| Firmware update | Over RS485 with the management utility |
| Configuration | Parameters updated with the management utility |
| Keypad | None (card-only) or touch keypad (-K variant) |
Security
| Tamper | Tamper alarm on removal from the mounting surface |
|---|---|
| Metal mounting | Metal middle frame reduces the effect of metal mounting surfaces |
Electrical
| Supply voltage | 9–15 V DC |
|---|---|
| Current at 12 V | ≈ 100 mA standby, ≈ 150 mA operating |
Mechanical & environment
| Dimensions | 93.3 × 93 × 19.3 mm (±0.5 mm) |
|---|---|
| Mounting | Wall mount |
| Ingress protection | IP65 |
| Operating temperature | –20 to +65 °C (–4 to +149 °F) |
| Operating humidity | 20–80% RH, non-condensing |
| Storage temperature | –40 to +80 °C (–40 to +176 °F) |
| Certifications | None listed; confirm marking requirements for your market |
Supported credentials
| Band | Standards | Card and tag types |
|---|---|---|
| 13.56 MHz | ISO/IEC 14443A, ISO/IEC 14443B, ISO/IEC 18092 | MIFARE Classic, MIFARE DESFire EV1/EV2, MIFARE Ultralight, MIFARE Ultralight C, NTAG2xx, CPU (microprocessor) smart cards, NFC Forum Type 1/2/4 tags |
Encrypted content can be read from CPU smart cards; read range is 0–3 cm depending on card and installation.
Tamper-alarm reader family at a glance
| SKU | Frequencies | Housing | Notes |
|---|---|---|---|
| TP-120 | 125 kHz + 13.56 MHz | 86 × 86 × 15.6 mm | Dual frequency, 86 mm footprint |
| TP-130 | 13.56 MHz | 86 × 86 × 15.6 mm | HF only, 86 mm footprint |
| TP-140 | 125 kHz + 13.56 MHz | 93.3 × 93 × 19.3 mm | Dual frequency, larger square face |
| TP-150 | 13.56 MHz | 93.3 × 93 × 19.3 mm | HF only, metal middle frame for metal mounts |
All four: IP65, tamper alarm, Wiegand or RS485, 9–15 V DC, 0–3 cm read range, card-only or touch-keypad version.
Specifications can change between production batches. Confirm the current revision with us before placing volume orders.
Ordering options
Quote the SKU that matches your frequency, interface and mounting. Not sure? Send us your controller model and we will pick the variant for you.
| SKU | Configuration | Actions |
|---|---|---|
| TP-150-MS | Card-only, 13.56 MHz, metal middle frame, tamper alarm, IP65, Wiegand/RS485, 93 mm square | |
| TP-150-MS-K | Touch-keypad version, 13.56 MHz, metal middle frame, tamper alarm, IP65, Wiegand/RS485, 93 mm square |
Where the TP-150 is used
- Readers on steel door frames and metal gate posts
- Turnstile and speed-gate cabinets with metal enclosures
- Elevator lobby panels with metal faceplates
- Sites moving from UID-only cards to encrypted CPU cards
Elevator Access Control Readers
Elevator card readers for car panels and lift lobbies: anti-clone encrypted cards, QR codes for visitors, Wiegand or RS485 output to the floor controller.
Turnstile & Speed-Gate Readers: QR, RFID and Face
Turnstile card readers, QR scanners and face terminals for tripod, swing and speed gates, with Wiegand, RS485, RS232 or TTL output to the gate board.
TP-150 FAQ
Why does the metal middle frame matter?
Metal behind a 13.56 MHz reader can shorten or disrupt reading. The metal middle frame reduces that effect, so performance is more consistent on metal mounts.
Does it read 125 kHz cards?
No, it is 13.56 MHz only. For 125 kHz and 13.56 MHz in one reader, see TP-140 (same 93 mm size) or TP-120 (86 mm).
What outputs are available?
Wiegand and RS485. The RS485 line also carries firmware updates from the management utility.
What are the power requirements?
9–15 V DC; at 12 V, about 100 mA on standby and about 150 mA while reading.
Is there a keypad version?
Yes. TP-150-MS-K adds a touch keypad in the same housing.
